Model
XDA75, XDA100, XDA120, XDA150

Item specifics

Thermal protector:
with thermal protector (single phase motor)
Insulation rating:
F
Protection class:
IP55
Medium temperature:
5~50℃
Ambient temperature:
≤50℃
Maximum working pressure:
0.3MPa

Review

Description

Bathtub Water Pump Introduction

The pump is equipped with water pressure type waterless protection, and the pressure sampling and electric pump are integrated. The conduction pressure of the pressure switch is directly sampled from the pressure generated by the electric pump itself when it rotates. When there is no medium in the pump body, the water pressure switch cannot be turned on, thereby achieving the purpose of preventing the electric pump from operating when there is no water in the bathtub.

Bathtub Water Pump Parameter

Bathtub Water Pump Parameter

Bathtub Water Pump Performance Curves

Bathtub Water Pump Performance Curves

Bathtub Water Pump Dimension

Bathtub Water Pump Dimension

Bathtub Water Pump Exploded View

Bathtub Water Pump Exploded View
NO.
NAME
1
Tie-in Nut
2
Tie
3
O-Ring
4
Hexagon Bolt
5
Washer
6
 Pump Casing
7
O-Ring
8
Upper Cover
9
Cross Recessed Pan Head Tapping Screw
10
Float
11
Plastic Spacer
12
Air Drain Plug
13
Guide Plate
14
Impeller
15
Mechanical seal
16
Shaft Sleeve
17
O-Ring
18
 Pump Cover
19
 Motor

Bathtub Water Pump Applications

Bathtub Water Pump Applications
