SPA Water Pump 56WUA200/300/350/400 Series Wholesale | Long-Life Low-Maintenance Whirlpool Pump for Hot Tub | Manufacturer Direct Supply
- Model
- 56WUA200-Ⅰ, 56WUA300-Ⅰ, 56WU350-Ⅰ, 56WUA400-Ⅰ, 56WUA200-Ⅱ, 56WUA300-Ⅱ,56WUA350-Ⅱ, 56WUA400-Ⅱ
Item specifics
- Thermal protector:
- with thermal protector( single phase motor)
- Insulation rating:
- F
- Medium temperature:
- 5~50℃
- Ambient temperature:
- ≤50℃
- Maximum working pressure:
- 0.3MPa
- Certification:
- UL ; ETL
Review
Description
Attention: P1 is the input power and P2 is the output power. Please confirm whether the power of the pump matches before purchasing.
SPA Water Pump Introduction
56WUA200/300/350/400 series pump cover can be rotated at 12:00, 9:00, 3:00, location, which is convenient for pipeline installation.
SPA Water Pump Parameter
SPA Water Pump Performance Curves
SPA Water Pump Dimension
SPA Water Pump Exploded View
NO. | NAME | |||
1 | Tie-in Nut | |||
2 | Tie | |||
3 | O-Ring | |||
4 | Drainage Plug | |||
5 | O-Ring | |||
6 | Cross Recessed Pan Head Screw and Washer Assembling | |||
7 | Pump Cover | |||
8 | O-Ring | |||
9 | Activities Rings | |||
10 | Impeller | |||
11 | Mechanical seal | |||
12 | Pump Casing | |||
13 | Motor | |||
SPA Water Pump Applications
