Bathtub Air Blower APW Series | Optional Switch and Large Volume Air Pump for Whirlpool Hot Tub | Support Bulk Order
- Model
- APW300-1, APW400-1, APW700-1, APW900-1. APW300-2, APW400-2, APW700-2, APW900-2
Item specifics
- Thermal protector:
- with thermal protector
- Insulation rating:
- A
- Medium:
- dry air
- Ambient temperature:
- ≤40℃
- Maximum working pressure:
- 0.1MPa
Review
Description
Bathtub Blower Parameter
Optional air switch
Bathtub Blower Dimension
*When D in fig.is thread connection, ф 32, ф 33.5 and ф 48.5 unions are available.
*When D in fig.is direct connection, only ф 48.5 pipe is available.
Bathtub Blower Exploded View
NO. | NAME | |||
1 | Tie-in nut | |||
2 | Tie | |||
3 | Cross recessed pan head screws | |||
4 | Upper part of housting | |||
5 | Themal protector | |||
6 | Cross recessed pan head tappig screws | |||
7 | Heater | |||
8 | Motor | |||
9 | Shock absorber | |||
10 | Cross recessed pan head tappig screws | |||
11 | Cable gland | |||
12 | Bottom part of housing | |||
13 | Hexagonal Nut | |||
14 | Cable head | |||
15 | Cable | |||
16 | Switch assembling | |||
17 | Cross recessed pan head tappig screws | |||
18 | Intake-tube | |||
19 | Sponge cushion | |||
20 | Sponge cushion | |||
21 | Air cover | |||
22 | Silent block | |||
Bathtub Blower Installation Diagram
Bathtub Blower Applications
