Bathtub Blower APW-G Series Wholesale | Large Air Volume Silent AIr Pump | Top Manufacturer and Supplier from China

Model: APW400-1-G, APW700-1-G, APW900-1-G, APW400-2-G, APW700-2-G, APW900-2-G

Item specifics

Bathtub Blower Parameter

Optional air switch

Bathtub Blower Dimension

*When D in fig.is thread connection, ф 32, ф 33.5 and ф 48.5 unions are available.

*When D in fig.is direct connection, only ф 48.5 pipe is available.

Bathtub Blower Exploded View

NO.		NAME
1		Tie-in nut
2		Tie
3		Cross recessed pan head screws
4		Upper part of housing
5		Themal protector
6		Cross recessed pan head tappig screws
7		Heater
8		Motor
9		Shock absorber
10		Cross recessed pan head tappig screws
11		Cable gland
12		Bottom part of housing
13		Hexagonal Nut
14		Cable head
15		Cable
16		Switch assembling
17		Cross recessed pan head tappig screws
18		Intake-tube
19		Sponge cushion
20		Sponge cushion
21		Air cover
22		Silent block

Bathtub Blower Installation Diagram
